Riverflex suction hose are a challenge to the best products in the industry. It has a rigid spiral PVC reinforcement between soft walls which make it an ideal replacement to rubber hose. It is lightweight and extremely flexible giving it very good usability. It is smooth inside and outside which gives it excellent resistance to pressure, making it ideal for irrigation purpose in agriculture, saline water treatment, light acids, alkalies and other chemicals except solvents
| Description | Size (mm) | Wall Thickness (mm) | Dimensions (mm) + 0.75 mm | Pressure Kg/cm2 at 20 deg | Coil Length | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| ID | OD | WP | BP | ||||||||
| Suction Hose (Medium Duty) | 20 | 4 | 20 | 28 | 7 | 21 | 30/50/100 | ||||
| 25 | 4.5 | 25 | 34 | 7 | 21 | 30/50/100 | |||||
| 30 | 5 | 30 | 40 | 6.5 | 19.5 | 30/50/100 | |||||
| 40 | 5.5 | 40 | 51 | 5 | 15 | 30/50/100 | |||||
| 50 | 6 | 50 | 62 | 4 | 12 | 30/50/100 | |||||
| 65 | 6.5 | 65 | 78 | 4 | 12 | 30/50/100 | |||||
| 75 | 7 | 75 | 89 | 3.5 | 10.5 | 50/100 | |||||
| 100 | 7.5 | 100 | 115 | 3.5 | 10.5 | 30/50/100 | |||||
| RIVERFLEX MEDIUM DUTY GREEN SUCTION HOSE | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Size | Size | Diameter | Bending Radius MM | Pressure (at 30o C) | Standard Lengths MTRS | |||||||
| MM | INCH | ID MM | OD MM | Working kg/CM2 | Bursting kg/CM2 | |||||||
| 20 | 3/4" | 19.0 +-0.5 | 23.6 +-1.0 | 45 | 7.0 | 24.0 | 30/50 | |||||
| 25 | 1" | 25.4 +-0.5 | 30.0 +-1.0 | 55 | 7.0 | 23.0 | 30/50 | |||||
| 30 | 1.25" | 31.8 +-0.5 | 36.8 +-1.0 | 75 | 6.5 | 20.0 | 30/50 | |||||
| 40 | 1.50" | 38.0 +-0.5 | 43.3 +-1.0 | 95 | 5.0 | 16.0 | 30/50 | |||||
| 50 | 2" | 50.8 +-0.5 | 57.8 +-1.5 | 122 | 4.0 | 16.0 | 30/45/50 | |||||
| 65 | 2.50" | 63.5 +-1.0 | 72.0 +-1.5 | 160 | 4.0 | 16.0 | 30/45 | |||||
| 75 | 3" | 76.2 +-1.0 | 85.0 +-1.5 | 272 | 3.5 | 15.0 | 30/36 | |||||
| 100 | 4" | 101.2 +-1.0 | 112.2 +-2.0 | 290 | 3.5 | 11.0 | 15/18/30 | |||||
