Nominal Size inches | Size mm | I.D. mm | O.D. mm | Bending Radius mm | Working Pressure kg/cm @ 300 C | Standard Length mtrs |
---|---|---|---|---|---|---|
1 | 25 | 25.0* | 1.5* | 50 | 8.0 | 30 |
11/2 | 30 | 31.8* | 38.0* | 70 | 7.0 | 30 |
11/2 | 38 | 38.0* | 46.3*** | 80 | 3.5 | 30 |
2 | 50 | 50.8* | 60.8*** | 110 | 4.5 | 30 |
21/2 | 65 | 63.5*** | 74.5*** | 140 | 4.5 | 30 |
3 | 75 | 76.2** | 87.2*** | 175 | 4.5 | 30 |
4 | 100 | 101.2*** | 114.2**** | 240 | 4.0 | 15 / 18 |
5 | 125 | 127.0*** | 141.0**** | 280 | 3.0 | 15 / 18 |
6 | 150 | 152.4*** | 169.4**** | 400 | 2.5 | 15 / 18 |
8 | 200 | 203.2**** | 224.4**** | 650 | 2.5 | 4.5 / 6 |
10 | 250 | 245.0**** | 284.0**** | 1000 | 2.0 | 4.5 / 6 |
Nominal Size inches | Size mm | I.D. mm | O.D. mm | Bending Radius mm | Working Pressure kg/cm @ 300 C | Standard Length mtrs |
---|---|---|---|---|---|---|
1/2 | 20 | 19.0* | 23.6** | 45 | 7.0 | 30 |
1 | 25 | 25.0* | 30.0** | 60 | 7.0 | 30 / 45 |
11/2 | 30 | 31.8* | 36.8** | 80 | 6.5 | 30 / 45 |
11/2 | 38 | 38.0* | 43.3** | 110 | 5.0 | 30 / 45 |
2 | 50 | 50.8* | 57.8** | 130 | 4.0 | 30 / 45 |
21/2 | 65 | 63.5*** | 72.0** | 175 | 4.0 | 30 / 45 |
3 | 75 | 76.2** | 85.0** | 275 | 3.5 | 30 / 45 |
4 | 100 | 101.2*** | 112.2** | 310 | 3.5 | 30 |
Nominal Size inches | Size mm | I.D. mm | O.D. mm | Bending Radius mm | Working Pressure kg/cm @ 300 C | Standard Length mtrs |
---|---|---|---|---|---|---|
1 / 2 | 20 | 19.0* | 24.6* | 45 | 8.5 | 30 |
1 | 25 | 25.0* | 31.0* | 50 | 8.0 | 30 |
11/2 | 30 | 31.8* | 38.8 | 60 | 7.0 | 30 |
11/2 | 38 | 38.0* | 46.3*** | 80 | 3.5 | 30 |
2 | 50 | 50.8* | 60.8*** | 110 | 4.5 | 30 |
21/2 | 65 | 63.5*** | 74.5*** | 130 | 4.5 | 30 |
3 | 75 | 76.2** | 87.2*** | 175 | 4.5 | 30 |
